Optional center caps available for Gram Lights 57Pro $30.00 each |
Titan Lip! |
Gram Lights 57 PRO
|
The Gram Lights 57Pro wheels are Discontinued and are no longer available in sets. Please check our Clearance Section for Single wheels still available. |
The Gram Lights 57 Pro is a 2 pc Cast wheel with a Polished Stainless Steel Lip. Standard Color - Grey Silver. RMC finish add $127.00 per wheel. Titan Lip add $254.00 per wheel. The Gold finish center is Discontinued. 2.12
Click here for Wheel Fitment Guide - Gram Lights Center Caps
| SIZE | DISK | STANDARD OFFSET | FREE OFFSET | SPECIAL OFFSET | HOLE | P.C.D. | List Price Each | Sale Price Each | |
| (RIM DEPTH/mm) | (RIM DEPTH/mm) | (RIM DEPTH/mm) | |||||||
|
15 |
5 1/2 | A | +40 / 22mm | +42 / 20mm - +25 / 37mm | 4 | 100 | $430.00 | Discontinued | |
| B | +37 / 37mm +43 / 31mm | +43 / 31mm - +37 / 37mm | |||||||
| A | +42 / 20mm - +25 / 37mm | 114.3 | |||||||
| B | +43 / 31mm | +43 / 31mm - +37 / 37mm | |||||||
| 6 1/2 | A | +25 / 50mm, +35 / 40mm, +45 / 30mm | +45 / 29.5mm - +13 / 61.5mm | 4 | 100 | $450.00 | Discontinued | ||
| B | +43 / 43.5mm - +25 / 61.5mm | ||||||||
| A | +25 / 50mm, +35 / 40mm | +45 / 29.5mm - +13 / 61.5mm | 114.3 | ||||||
| B | +43 / 43.5mm - +25 / 61.5mm | ||||||||
| 7 1/2 | A | +25 / 63mm | +45 / 42.5mm - ±0 / 87.5mm | 4 | 100 | $470.00 | Discontinued | ||
| B | +43 / 56.5mm - +12 / 87.5mm | ||||||||
| A | ±0 / 88mm, +15 / 73mm, +25 / 63mm | +45 / 42.5mm - ±0 / 87.5mm | 114.3 | ||||||
| B | +43 / 56.5mm - +12 / 87.5mm | ||||||||
| SIZE | DISK | STANDARD OFFSET | FREE OFFSET | SPECIAL OFFSET | HOLE | P.C.D. | List Price Each | Sale Price Each | |
| (RIM DEPTH/mm) | (RIM DEPTH/mm) | (RIM DEPTH/mm) | |||||||
|
17 |
7.0 | B | +40 / 36mm | 4 | 100 | $838.00 | Discontinued | ||
| A | +25 / 36mm | 114.3 | |||||||
| B | +40 / 36mm | ||||||||
| B | +40 / 36mm | 5 | 100 | ||||||
| C | +48 / 36mm | ||||||||
| A | +25 / 36mm | 114.3 | |||||||
| B | +40 / 36mm | ||||||||
| C | +48 / 36mm | ||||||||
| 8.0 | A | +12/61.5mm | 4 | 114.3 | $863.00 | Discontinued | |||
| B | +27/61.5mm | 4 | 114.3 | ||||||
| C | +35 / 61.5mm | 4 | 114.3 | ||||||
| B | +27/61.5mm, +40 / 48.5mm, +46/42.5mm | 5 | 100 | ||||||
| A | +12/61.5mm, +25 /48.5mm, +30 / 42.5mm | 114.3 | |||||||
| B | +27/61.5mm, +40 / 48.5mm | ||||||||
| C | +35 / 61.5mm, +48 / 48.5mm | ||||||||
| 9.0 | B | +27 / 74.3mm | 4 | 114.3 | $889.00 | Discontinued | |||
| C | +35 / 74.3mm | 4 | |||||||
| A | +12 / 74mm, +25 / 62mm, +30 / 55mm | 5 | |||||||
| B | +27/74.3mm, +40 / 62mm | ||||||||
| C | +35 / 74mm | ||||||||
| SIZE | DISK | STANDARD OFFSET | FREE OFFSET | SPECIAL OFFSET | HOLE | P.C.D. | List Price Each | Sale Price Each | |
| (RIM DEPTH/mm) | (RIM DEPTH/mm) | (RIM DEPTH/mm) | |||||||
|
18 |
7.5 | A | +30 / 34.5mm | +30 / 34.5mm - -10 / 74.5mm | -11 / 75.5mm - -25 / 89.5mm | 4 | 114.3 | $940.00 | Discontinued |
| B | +22 / 52.5mm, +40 / 34.5mm | +40 / 34.5mm - ±0 / 74.5mm | -1 / 75.5mm - -15 / 89.5mm | ||||||
| C | +52 / 34.5mm - +12 / 74.5mm | +11 / 75.5mm - -3 / 89.5mm | |||||||
| B | +40 / 34.5mm | +40 / 34.5mm - ±0 / 74.5mm | -1 / 75.5mm - -15 / 89.5mm | 5 | 100 | ||||
| C | +48 / 38.5mm | +52 / 34.5mm - +12 / 74.5mm | +11 / 75.5mm - -3 / 89.5mm | ||||||
| A | +30 / +34.5mm | +30 / 34.5mm - -10 / 74.5mm | -11 / 75.5mm - -25 / 89.5mm | 114.3 | |||||
| B | +22 / 52.5mm, +40 / 34.5mm | +40 / 34.5mm - ±0 / 74.5mm | -1 / 75.5mm - -15 / 89.5mm | ||||||
| C | +52 / 34.5mm - +12 / 74.5mm | +11 / 75.5mm - -3 / 89.5mm | |||||||
|
18 |
8.0 | A | +30 / 40.5mm - -16 / 86.5mm | -17 / 87.5mm - -31 / 101.5mm | 4 | 114.3 | $952.00 | Discontinued | |
| B | +40 / 40.5mm | +40 / 40.5mm - -6 / 86.5mm | -7 / 87.5mm - -21 / 101.5mm | ||||||
| C | +52 / 40.5mm - +6 / 86.5mm | +5 / 87.5mm - -9 / 101.5mm | |||||||
| B | +40 / 40.5mm | +40 / 40.5mm - -6 / 86.5mm | -7 / 87.5mm - -21 / 101.5mm | 5 | 100 | ||||
| C | +52 / 40.5mm - +6 / 86.5mm | +5 / 87.5mm - -9 / 101.5mm | |||||||
| A | +30 / 40.5mm | +30 / 40.5mm - -16 / 86.5mm | -17 / 87.5mm - -31 / 101.5mm | 114.3 | |||||
| B | +22 / 58.5mm, +40 / 40.5mm | +40 / 40.5mm - -6 / 86.5mm | -7 / 87.5mm - -21 / 101.5mm | ||||||
| C | +52 / 40.5mm - +6 / 86.5mm | +5 / 87.5mm - -9 / 101.5mm | |||||||
|
18 |
8.5 | A | +43 / 34mm - -22 / 99mm | -23 / 100mm - -37 / 114mm | 4 | 114.3 | $965.00 | Discontinued | |
| B | +40 / 47mm | +52 / 35mm - -12 / 99mm | -13 / 100mm - -27 / 114mm | ||||||
| C | +52 / 47mm - ±0 / 99mm | -1 / 100mm - -15 / 114mm | |||||||
| B | +52 / 35mm - -12 / 99mm | -13 / 100mm - -27 / 114mm | 5 | 100 | |||||
| C | +52 / 47mm - ±0 / 99mm | -1 / 100mm - -15 / 114mm | |||||||
| A | +30 / 47mm | +43 / 34mm - -22 / 99mm | -23 / 100mm - -37 / 114mm | 114.3 | |||||
| B | +22 / 65mm, +40 / 47mm | +52 / 35mm - -12 / 99mm | -13 / 100mm - -27 / 114mm | ||||||
| C | +52 / 47mm - ±0 / 99mm | -1 / 100mm - -15 / 114mm | |||||||
|
18 |
9.0 | A | +43 / 40.3mm - -28 / 111.3mm | -29 / 112.3mm - -43 / 126.3mm | 4 | 114.3 | $978.00 | Discontinued | |
| B | +52 / 41.3mm - -18 / 111.3mm | -19 / 112.3mm - -33 / 126.3mm | |||||||
| C | +52 / 53.3mm - -6 / 111.3mm | -7 / 112.3mm - -21 / 126.3mm | |||||||
| B | +52 / 41.3mm - -18 / 111.3mm | -19 / 112.3mm - -33 / 126.3mm | 5 | 100 | |||||
| C | +52 / 53.3mm - -6 / 111.3mm | -7 / 112.3mm - -21 / 126.3mm | |||||||
| A | +12 / 71.3mm | +43 / 40.3mm - -28 / 111.3mm | -29 / 112.3mm - -43 / 126.3mm | 114.3 | |||||
| B | +22 / 71.3mm, +40 / 53.3mm | +52 / 41.3mm - -18 / 111.3mm | -19 / 112.3mm - -33 / 126.3mm | ||||||
| C | +38 / 67.3mm | +52 / 53.3mm - -6 / 111.3mm | -7 / 112.3mm - -21 / 126.3mm | ||||||
|
18 |
9.5 | A | +43 / 46.7mm - -34 / 123.7mm | -35 / 124.7mm - -49 / 138.7mm | 4 | 114.3 | $990.00 | Discontinued | |
| B | +52 / 47.7mm - -24 / 123.7mm | -25 / 124.7mm - -39 / 138.7mm | |||||||
| C | +52 / 59.7mm - -12 / 123.7mm | -13 / 124.7mm - -27 / 138.7mm | |||||||
| B | +52 / 47.7mm - -24 / 123.7mm | -25 / 124.7mm - -39 / 138.7mm | 5 | 100 | |||||
| C | +52 / 59.7mm - -12 / 123.7mm | -13 / 124.7mm - -27 / 138.7mm | |||||||
| A | +12 / 77.7mm, +30 / 59.7mm | +43 / 46.7mm - -34 / 123.7mm | -35 / 124.7mm - -49 / 138.7mm | 114.3 | |||||
| B | ±0 / 99.7mm, +22 / 77.7mm, +40 / 59.7mm | +52 / 47.7mm - -24 / 123.7mm | -25 / 124.7mm - -39 / 138.7mm | ||||||
| C | +52 / 59.7mm - -12 / 123.7mm | -13 / 124.7mm - -27 / 138.7mm | |||||||
|
18 |
10.0 | A | +38 / 58mm - -41 / 137mm | -42 / 138mm - -56 / 152mm | 4 | 114.3 | $1,003.00 | Discontinued | |
| B | +48 / 58mm - -31 / 137mm | -32 / 138mm - -46 / 152mm | |||||||
| C | +52 / 66mm - -19 / 137mm | -20 / 138mm - -34 / 152mm | |||||||
| B | +48 / 58mm - -31 / 137mm | -32 / 138mm - -46 / 152mm | 5 | 100 | |||||
| C | +52 / 66mm - -19 / 137mm | -20 / 138mm - -34 / 152mm | |||||||
| A | +12 / 84mm | +38 / 58mm - -41 / 137mm | -42 / 138mm - -56 / 152mm | 114.3 | |||||
| B | +22 / 84mm | +48 / 58mm - -31 / 137mm | -32 / 138mm - -46 / 152mm | ||||||
| C | +38 / 38mm | +52 / 66mm - -19 / 137mm | -20 / 138mm - -34 / 152mm | ||||||
| ●The 18-inch OFFSET A in the size table denote models matching big calipers of SKYLINE, FAIRLADY Z, SILVIA, CELSIOR, SUPRA, RX-7, LANCER and IMPREZA (GDB) and GTO. | |||||||||
| ●The 18-inch OFFSET B and 17-inch OFFSET A in the size table denote models matching big calipers of SKYLINE (excluding CPV35/BREMBO calipers), | |||||||||
| FAIRLADY Z（excluding Z33/BREMBO calipers）, SILVIA, CELSIOR, SUPRA, RX-7 and IMPREZA (GDB). | |||||||||
| ●The OFFSET C in the size table denotes models matching big calipers of IMPREZA (GC8) and INTEGRA (DC5). | |||||||||
| ●The depth of rims in the size table denotes the length from flanges to faces of disks. | |||||||||
The Gram Lights 57 Pro are available in Grey Silver. RMC finish add $127.00 per wheel. Titan Lip add $254.00 per wheel.
Click here for Wheel Fitment Guide - Gram Lights Center Caps
The Gram Lights 57Pro wheels are now Discontinued and are no longer available in sets. Please check our Clearance Section for Single wheels still available.
Optional Gram Lights WR Type Center caps. Red, Black Silver. $38.00 per cap.
